Specification:
Dimension | 40*33*6.5 mm | ||
LED No | 1 pcs 5074 SMD LED | ||
Voltage | Input 12VDC | ||
View angle | 120 degree | ||
Current | 100 mA | 100 mA | 100 mA |
Watts | 1.2 | 1.2 | 1.2 |
Lumen | 120 | 120 | 120 |
Color | White | Warm white | Cool white |
Cover | Milky white ABS | ||
IP rate | IP67 | ||
Working temp | -20～+60℃ | ||
Max connection | 20 pcs per a string | ||
Life | 50,000 hrs. Lumen Maintenance:>97%@5,000hrs | ||
Warranty | 36 months | ||
Certificate | CE:BTRE0708181359 / RoHS: BTRS0708310889 | ||
Part No | S5074-1W | S5074-1WW | S5074-1CW |
Feature:
1. Adopt TOP 5074 SMD LED, High Luminous Efficiency , with a low lumen recession and good consistency.
2. With a low power consumption and high lumen value, a long life-span, maintenance-free.
3. With aluminum pcb based, this unique structure grants a better cooling effect.
4. IP Rate: IP67
5. Adopted Constant Voltage Technology. DC12V, safty.
6. Adopt series-parallel connection circuit, 20Pcs for 1 string, each module could be singled out.
Application:
This product is applicable for 12-25cm glowing character, advertisement board, light box or local lighting.
