Procuct Detail

5050 Injection led module Constact current

Specification:

Dimension	35355.8 mm
LED No	4 pcs 5050 SMD LED
Voltage	Input 12VDC
View angle	120 degree
Current	80 mA	80 mA	80 mA		80 mA		80 mA
Watts	0.96	0.96	0.96		0.96		0.96
Lumen	80	14	40		24		28
Color	White	Blue	Green		Yellow		Red
Cover	Milky white ABS
IP rate	IP67
Working temp	-20～+60℃
Max connection	50 pcs per a string
Life	50,000 hrs. Lumen Maintenance:>97%@5,000hrs
Warranty	5 years
Certificate	CE:BTRE0708181359 / RoHS: BTRS0708310889
Part No	SZ-35354W-50	SZ-35354B-50		SZ-35354G-50		SZ-35354Y-50		SZ-35354R-50

Feature:
1. Adopt 4 pcs TOP 5050 SMD LED, tri-chip led, Orignal Epistar chip from Taiwan.
2. High brightness, 20 lumen per single led.
3. Aluminum PCB based, very good heat dissipation.
4. Built-in constant current control IC,reliable and long lifespan
5. DC 12V low voltage input, reliable and safe.
6. 50 Pcs for 1 string, each module could be singled out.
7. Injection ABS shell, waterproof, IP 67.
8. CE&ROHS approved.

Application:
widely used for signs,channel letters,light boxes etc. with high brightness,colorful and energy saving benefits
