Specification:
Dimension | 35*35*4 mm | ||||
LED No | 4 pcs 3528 SMD LED | ||||
Voltage | Input 12VDC | ||||
View angle | 120 degree | ||||
Current | 40mA | 40mA | 40mA | 60mA | 60mA |
Watts | 0.48 | 0.48 | 0.48 | 0.72 | 0.72 |
Lumen | 25.2 | 3.5 | 13 | 5.6 | 8.4 |
Cover | Aluminum case | ||||
Life | 50,000 hrs. Lumen Maintenance:>97%@5,000hrs | ||||
Color | White 3500~8000k | Blue | Green | Yellow | Red |
Operation Temperature | -40��- 60�� (-40~140) | ||||
Certificate | CE:BTRE0708181359 / RoHS: BTRS0708310889 | ||||
Warranty | 36 months | ||||
Weight | 10 g/pc. | ||||
IP | IP65 The PCB be covered by resin. | ||||
Part No | STF-334W-35 | STF-334B-35 | STF-334G-35 | STF-334Y-35 | STF-334X-35 |
Features:
1. High Brightness
4 pcs 3528 SMD LED Modules, 26-28 lumen per module
2. High color consistency
No Spot, No light shadow.
3. Easy install.
20 pcs per a string, each module could be single out. Every module with 3M tape on its back.
