Specification:
LED Type | 3535 LED |
LED BRAND | GENESIS |
Viewing Angle | 160�� |
Luminous Flux(lm) | 160 LM |
LED Qty | 1 pcs |
Life Span | 80,000 H |
Working Voltage | DC12V |
Consumption | 2 W |
Driving Method | constant voltage |
Stand Length In Serial Connection | 20pcs |
Maximum Length In Serial Connection | ��20pcs |
Shell | Milk white ABS |
Dimension | 45*35 mm |
Available Color | White |
Certification | CE&ROHS |
Working Temperature | -20�� ���� +60�� |
Store Temperature | -50�� ���� +60�� |
IP Degree | IP65 |
1. With series-parallel connection circuit forled pcb, each string has 20pcs and each module can be cut individually.
2. Take 3535LED as light source, no lightspot, low decay and good consistency.
3. The LED passed America LM80 standard, 5years quality warranty.
4. ABS Injection outer cover, beautiful andunique appearance, good heat dissipation.
5. Low consumption, high brightness, freemaintenance, long life span.
6. Input voltage: DC12V, reliable and safe.
7. Protect level: IP65,waterproof.
Application:
1. Backlight for the single side lighting box.
Package:
Every 20 pcs per a string, every 5 string inan anti-static bag, 1200 pcs per a carton box. Carton size: 50*35*31.5 cm.
Net Weight: 15 g/pc; 300 g/string; 18kg/carton.
Dimension Diagram(mm):
Connection Diagram:
