Procuct Detail

Waterproof Smart RGB LED Module

Specification:

Dimension	L91XW15XH13mm
LED No	9
Voltage	12V DC
View angle	180
Current	20 mA
Watts	Max.0.72
Lumen	Max. 18
Cover	Milky ABS
Color	RGB
Operation Temperature	-40��- 60�� (-40~140)
Warranty	24 months
Weight	12g
IP	65
Part No	SCF-75159RGBI

Features:

1. TOP 9 pcs strawhat LED and 1 pcs LPD1101 IC adopts.

2. Controller: T-1000c, with SD card in it.
the color effects could be custom-made, our engineer will design your own color effects for you, then store it in the SD card.

3. Durable epoxy resin fill for waterproof (IP65) rating

4. CE&ROHS approved.

5. 50,000 hrs life time, 24 month warranty.

6. The variable color effects will make your signage more attractive.
